SA Weld 4.0MIG180i Multi Purpose Welder Inverter

About

MIG 180i is an industrial quality multiprocess single phase welding machine designed to get the job done whilst offering exceptional arc stability. This machine offers Stick, Tig, Flux-cored gasless, Mig - backed up by a 12-month parts and labour warranty. Ideally suited for the small fabricator or serious DIY enthusiast that demands exceptional quality and reliability.

Product Features

• Smooth stable ARC
• Adjustable inductance to optimise GMAW weld setting
• Adjustable burnback to ensure proper end of weld setting
• Thermal overload protection
• Built-in hotstart for easy ARC ignition
• Digital display for fine adjustment of the perfect weld setting
• 2 roll wirefeeding system
• Uses 5kg spools
• Robust case design
• Enclosed wirefeeding protects wire from dust and grinding
• Applications:
• Maintenance and repair
• Sheet metal fabrication
• Agriculture
• Automotive body shops
• Output Range: 30-180amps
• Dimensions (L X W X H): 553 x 214 x 388 mm
• Wire Size:
• GMAW: 0.6-0.8mm
• FCAW-SS:0.9-1.2mm
• Dry Weight: 12kg
• Material to be Welded: Carbon Steel/ Stainless Steel/ Low alloy steel
• Welding Process: Stick/ Tig/ Mig/ Fluxcored gasless

Product Specifications

• Input voltage: 1-ph 230VAC+/-15% 50/60HZ
• OCV: 62V
• Output voltage: MIG:11V--26V
• Output current: 30-180A
• Hot start: Built-in
• Arc force current: Built-in
• Warranty: 1 year
• What's Included:
• 1 x MIG180i Welder
• 1 x MB15 torch
• 1 x Gas hose
• 1 x Flow meter
• 1 x Earth cable and clamp
• 1 x Contact tip 0.8mm
