Yamaha8-Channel Live Streaming Mixer (Model: AG08)

About

Your Complete Command Centre for Streaming

The Yamaha AG08 is the flagship of Yamaha’s AG Series, designed for creators who demand professional-grade audio and maximum flexibility. Combining an 8-channel mixer, USB audio interface, onboard DSP effects, sound pads, and advanced routing capabilities, the AG08 is built for livestreaming, podcasting, gaming, voice-over work, music performance, and content creation. With studio-quality sound, intuitive controls, and extensive connectivity, it gives solo creators and multi-host productions everything needed to create polished, professional broadcasts.

Product Features

• 8-channel live streaming mixer with integrated USB audio interface
• Two mic/line inputs with +48V phantom power for professional microphones
• Hi-Z instrument input for guitars and other instruments
• Dual headphone outputs for hosts and guests
• Six customizable sound pads for triggering samples and effects
• Four FX preset buttons for quick audio enhancements
• Built-in DSP effects including Voice Changer, Reverb, Delay, Compressor, EQ, Amp Simulator, Ducker, and Maximizer
• 24-bit / 48kHz multichannel audio recording and playback
• USB-C connectivity for Windows, Mac, and mobile devices
• Flexible routing and assignable stereo channels for advanced streaming setups
• Smartphone connectivity via 3.5mm TRRS input/output
• Individual 60mm faders and mute buttons for precise control
• AG08 Controller software for detailed audio management
• Footswitch support for hands-free operation
• Includes Cubase AI, WaveLab Cast, and Cubasis LE software

Product Specifications

Audio & Performance

• Mixer Channels: 8 (2 Mono / 3 Stereo)
• Mic Preamps: 2
• Audio Resolution: 24-bit / 48kHz
• USB Audio Interface: 8 Inputs / 14 Outputs
• Sample Rate: 48kHz
• Phantom Power: +48V on CH1 & CH2
• Mix Routing: 4 Stereo Aux Buses / Subgroups

Inputs

• 2 x Combo XLR/TRS Mic/Line Inputs
• Hi-Z Guitar Input on CH2
• 2 x 1/4" Stereo Line Inputs
• 1 x RCA Stereo Input
• 1 x 3.5mm Stereo Input
• 1 x 3.5mm TRRS Smartphone Input
• USB-C Audio Input

Outputs

• 2 x Headphone Outputs
• Stereo Monitor Outputs (XLR/TRS)
• Stereo Main Outputs (TRS)
• Stereo Aux Send Output
• 3.5mm TRRS Smartphone Output
• Control Room / Monitor Outputs

Built-In DSP Effects

• Compressor
• Voice Changer
• Amp Simulator
• Reverb
• Delay
• Ducker
• Maximizer
• Four User-Assignable FX Presets

Streaming & Content Creation

• Six onboard sound pads for real-time sample triggering
• LOOPBACK functionality for streaming
• Individual mute buttons per channel
• AG08 Controller App (Windows, Mac, iOS)
• Footswitch support for scene and effect control

Connectivity

• USB-C Host Connection
• Windows Compatible
• macOS Compatible
• iOS Compatible (via Camera Adapter)
• Android Compatible via TRRS
• No Bluetooth Connectivity

Power

• Included Power Adapter: 12V DC / 1.5A
• USB-C Bus Power: 5V DC / 1.5A
• Maximum Power Consumption: 7.5W

Dimensions & Weight

• Dimensions: 290 x 222 x 88 mm
• Weight: Approx. 2.2 kg

Included Software

• Cubase AI
• WaveLab Cast
• Cubasis LE
• Warranty: 12 Months

What's in the Box?

• 1x Yamaha AG08 Live Streaming Mixer (Black)
• 1x AC Power Adapter
• 1x USB Cable
• Quick Start Guide
• Safety Documentation
• Cubase AI Download Information
• WaveLab Cast Download Information
• Cubasis LE Download Information
